K12 Adjustable Lift-Up Opening System

By Italiana Ferramenta

Measurement : Metric/Imperial

Length

Newton Force

Ordering information

With its compact, minimal design, the K12 System ADJ offers elegant lift-up options in various strengths and lengths, providing easy installation without extra screws for improved aesthetics and reduced assembly time.

Back to the top

Product Details

Brand
Italiana Ferramenta

Product Description

The K12 System ADJ, with its compact size and minimalist design, elevates elegance in every detail. This user-friendly solution eliminates the need for extra screws, enhancing aesthetics and cutting down assembly time. Featuring click-in door and side supports, it significantly reduces the risk of improper installation. The integrated mechanism allows for precise adjustment of the opening angle, ensuring perfect alignment of adjacent doors and smooth, continuous movement up to the maximum opening.

The K12 ADJ Lift-Up is compatible with both sprung and unsprung hinges. Additionally, the system is fully compliant with K Push Tech, making it ideal for seamless, handleless designs.

Sold by complete kit including the cabinet side bracket and 2 types of bracket for door (surface and recessed).
Product Advantages
- Reduced size and minimal design.
- Easy-to-install solution without the need for additional screws.
- Available in various strengths and lengths, versatile to fit various door dimensions and weights.
- The integrated mechanism for adjusting the opening angle ensures perfectly aligned nearby doors within the following tolerance:
  - L164mm = +8°/-3°
  - L244mm = +6°/-2°
  - L365mm = +4°/-1°
- Smooth and continuous door movement.
- Compatibility with Italiana Ferramenta Kimana hinge, and integration with Italiana Ferramenta K Push Tech Touch to Open hardware.
- Product tested and certified by CATAS®
Important Information
Resources
K12 ADJ System Technical Specifications K12 ADJ Lift-Up System Installation Instructions Line Art
