How System 32 Benefits Cabinet Makers

April 17, 2023

System 32 also known as "32mm system" or "32mm cabinet construction system" refers to a standardized system of measurements used in the construction of cabinets and other furniture.

The 32mm system originated in Europe in the 1960s and quickly gained popularity due to its simplicity, versatility, and efficiency. The system is based on a modular design that allows for easy and precise assembly of cabinets using standardized dimensions.

In System 32, cabinet parts are configured in multiples of 32mm in width, depth, and height. This allows for easy compatibility and interchangeability of parts between different manufacturers. It also makes it easy to add or replace components as needed.

The system is highly efficient in terms of material usage and production time. Cabinet components are cut from standard-sized panels and sheets, reducing waste and making it easier to estimate and manage material costs.

In addition to its practical benefits, System 32 also allows for a high degree of customization and design flexibility. Cabinet makers can easily create unique configurations and layouts by combining and arranging standard-sized components in various ways.

System 32 “Need-to-Know” Information

  • Hole Distance: 32mm
  • Drilling Diameter: 5mm (occasionally 8mm)
  • Front hole line to front edge distance: 37mm
  • Distance between holes: 32mm


Overall, the 32mm system has become a widely adopted standard in the cabinet making industry due to its many benefits. Whether you are a professional cabinet maker or a DIY enthusiast, understanding this system can help you create high-quality cabinets and furniture that are both functional and aesthetically pleasing.
